Manual Internal Line Up clamp
(Copyrighted product design – No. – A-113619/2015)
Product Description
The Manual Internal Line Up Clamp is a reliable and cost-effective pipe alignment tool designed to accurately align pipe ends during welding and pipeline installation. Operated through a manual mechanical expansion system, the clamp securely grips the inside diameter of adjoining pipes, ensuring precise alignment and maintaining a consistent root gap throughout the welding process.
Unlike pneumatic or hydraulic models, the Manual Internal Line Up Clamp requires no external power source, making it an ideal solution for remote locations, maintenance projects, fabrication workshops, and pipeline construction sites where compressed air or hydraulic systems are unavailable. Its rugged construction, simple operation, and low maintenance requirements make it a dependable choice for contractors and fabricators.
Manufactured from high-strength alloy steel with precision-machined components, the Manual Internal Line Up Clamp delivers accurate alignment, improved weld quality, and long-lasting performance in demanding industrial environments.
Key Features
- Manual mechanical expansion system
- Accurate internal pipe alignment
- No air or hydraulic power required
- Durable heavy-duty steel construction
- Easy to operate and maintain
- Lightweight and portable design
- Suitable for various pipe diameters
- Ensures consistent root gap during welding
- Improves weld quality and reduces rework
- Available in standard and custom sizes
Product Uses
The Manual Internal Line Up Clamp is designed to provide accurate internal pipe alignment during welding, fabrication, and installation operations.
Common Uses
- Aligning pipe ends before welding.
- Maintaining proper root gap during pipe fit-up.
- Supporting internal pipe alignment during fabrication.
- Improving weld accuracy and consistency.
- Reducing weld defects caused by pipe misalignment.
- Assisting in field pipeline installation.
- Supporting maintenance and repair projects.
- Preparing pipes for manual or automatic welding.
- Enhancing productivity in fabrication workshops.
- Providing reliable alignment where power sources are unavailable.
Applications
The Manual Internal Line Up Clamp is widely used in industries requiring accurate pipe alignment and high-quality welding.
Oil & Gas Pipeline Construction
Ensures precise alignment of crude oil, natural gas, and petroleum transmission pipelines before welding.
Cross-Country Pipeline Projects
Provides dependable internal alignment during long-distance pipeline installation in remote locations.
Petrochemical Plants
Supports process piping fabrication, maintenance, and expansion projects requiring precise weld preparation.
Refineries
Used for pipe alignment during refinery construction, equipment upgrades, and shutdown maintenance.
Water Transmission Projects
Facilitates accurate alignment of municipal and industrial water pipelines before welding.
Pipeline Fabrication Workshops
Ideal for pipe fit-up, welding, inspection, and assembly in fabrication yards.
Power Generation Plants
Supports the installation and maintenance of steam, cooling water, and process piping systems.
Also known as Internal Clamp, SSEGPL’s manual internal lineup clamp is as easy and quick solution for pipeline which is used by almost all pipeline contractors involved in construction of oil and gas pipeline. With the changes of pipe thickness the pipe clamps need to be changes. SSEGPL’s manual internal clamp available in sizes from 12″ to 48″.
| Product Name | Manual Internal Line-Up Clamp (MILUC) | ||||
| Product Name | Manual Internal Line-Up Clamp | Application | Internal pipe alignment for welding and fit-up | ||
| Application | Internal pipe alignment for welding and fit-up | Pipe Size | 6″ to 60″ (custom sizes available) | ||
| Pipe Size | 6″ to 60″ (custom sizes available) | Pipe Wall Thickness | 5 mm to 40 mm | ||
| Expansion Mechanism | Screw Jack / Cam Lever | Alignment Type | Internal Radial Alignment | ||
| Surface Finish | Powder Coated | Weight | Depends on pipe size | ||
| Weight | Depends on pipe size | ||||
| Brand | SSEGPL | ||||
| Country of origin | India | ||||
| Packing Type | Wooden box for International & loose packing for domestic | ||||
| *customzied on request* | |||||
Product Description
WHY CUSTOMERS PREFER SSEGPL MANUAL INTERNAL CLAMP?
- SSEGPL’s internal manual clamp available in wide range from pipe sizes from 12″ to 48″.
- Manual internal lineup clamp is designed for all diameters.
- Internal manual lineup clamp is quick reliable alternative to external line-up range.
- SSEGPL’s manual internal lineup clamp comes with heavy duty jack box for more power on the pipe with less efforts of operator.
QUICK HIGHLIGHT OF SSEGPL’S MANUAL INTERNAL LINEUP CLAMP
- 6” to 10” clamp works on specific wall thickness range.
- SSEGPL’S MANUAL INTERNAL LINEUP CLAMP ABOVE PIPE SIZE 12″ works on specified pipe thickness and Size.
- 6” to 10” have Screw jack type mechanism for adequate alignment.
- SSEGPL’S MANUAL INTERNAL LINEUP CLAMP ON SIZE ABOVE 12″ works on Toggle action puts maximum power on pipe.
- “Gap” is unobstructed for full stringer bead.
